IR-20 Infrared Irradiance Meter
High precision, wide measuring range, small size, low power consumption, stable performance, easy to use and easy to carry, portable infrared irradiance meter.
Measurable items
- Irradiance
- Irradiance difference
- irradiance ratio
- Integratingtime
- Integratingirradiance
- average irradiance
Technical Specifications
Sensor | 380nm ~ 1100nm, used for 850nm or 940nm infrared source |
Measurement range | 0.1 μW/cm2~2000 μW/cm2 |
Measurement accuracy | ±5％ (NIM, NIST) |
Display | 4 digits LCD |
Test rate | 5 times/s |
Communication | USB interface |
Power source | Two AA batteries |
