HAAS-2000 High Accuracy Array
HAAS-2000 High Accuracy Array Spectroradiometer delivers various photometric, colorimetric and radiometric parameters as required by CIE standards.With the highly matched high-precision grating and science-grade TC-cooling detector and BWCT technology with modified NIST stray light correction technology, the stray light reaches the extremely great level of 5.0E-05.
Powerful Functions
- Luminous Flux(lm), Luminous efficacy(lm/W), Spectral Power Distribution P(λ), Chromaticity Coordinate: (x,y), (u,v), Correlated Color Temperature Tc, Color Rendering Index: Ra, Ri (i=1~15), Standard deviation of color matching (SDCM), Peak Wavelength, Dominant Wavelength, Spectral Half Width, Colorimetric Purity, Radiant power, etc.
Technical Specifications for HAAS-2000
Model | HAAS-2000VIS | HAAS-2000IR1 | HAAS-2000IR2 | HAAS-2000UV |
Wavelength Range | 350nm-1000nm | 780nm-1650nm | 1600nm-2550nm | 200nm-400nm |
FWHM | 3.0nm | 9.0nm | 15.0nm | 1.0nm |
Wavelength Accuracy | ±0.3nm | ±0.5nm | ±3nm | ±0.1nm |
x,y Accuracy | ±0.0015(standard light source) | / | / | / |
x,y Repeatability | ±0.0003(standard light source ) ±0.00015x,±0.0002y(blue LED) | / | / | / |
CCT | 1000~1000000K | / | / | / |
Stray Light | <5E-5 | <1E-3 | <1E-3 | <1E-3 |
Power Supply Condition | AC 100~240V 50 Hz/60Hz(can be customized) | |||
*For more detailed technical specification, please contact Tenme.
